Product Name

Chemisorption Analyzer TPD/TPR/TPO

Charactieristics

Achieve 25 kinds experiments such as TPR,TPD,TPO,TPSR,pulse titration, pretreatment BET specific surface area ,Precious metal dispersity
-
Be suitable to 3 groups of carrier Gas,3 groups of reaction gas, and also can be extended to more extra 1-6 reaction gases
-
Gas flow control used by Digital Mass Flow Control (DMFC)
-
Reactor has many kinds of materials such as quartz, SS316L, and the proof pressure is up to 10MPa
-
Two and a half type tubular, the max temperature is up to 1100C, fast heating, cooling with cooling module
-
Built-in highly sensitive TCD ,FID, MS
-
Analysis workstation software can perform automatic controlling and analyze the dates that are collected
-
Quantitative analysis has an accurate precision, Adsorption Quantity, BET and Precious Metals Dispersity are quite accurate with good repeatability

Specifications

Operational Environment :0-50 C, 5%-95%Rh
Control Method :Software automatic controlling
Communication Methods :RS-485, upgraded to the USB or network interface
Built-in Detector :Superior sensitive TCD Detector Micro sample cell
Carrier Gas :He, Ar, N2, H2
Carrier Gas purity >99.995%
Reaction Materials :NH3, CO, CO2, H2,Methanol, ethanol, pyridine
Gas Flow Control :Digital Mass flow controller (DMFC) control, precision1%
Sample Volume :10-500mg
Reactor U Type, Quartz or SS316L , ID6mm, OD8mm, Pits or variable diameter
High Temperature Furnace Stainless steel shell tube furnace,Two structure,max temperature 1100C,Max High heating rate100C/min
Gas Circuit Switch Germany Bukert magnetic valve, Switzerland VICI Plane switch valve
Vapor Generator Soft package heating, temperature controller control
Constant current source 0-100mA, 0.1%precision, 1mAstep
Detector Micro TCD Detector, Min discriminable volume1*10-4cm3/g
Precision Veracity1%, Repeatability1%
Continuous Working Long cycle of continuous working
Anticorrosion Under the optimal situation, it can support acid-resistance, perbasic concentration gas
Software Special analysis workstation software, base on Windows platform
Data Export Support TXT Text Output, which makes the exchange data with drawing tools like Origin more convenient
